Unlimited Customization, Professional Performance — Configure Your Strength System to Fit Your Space, Brand, and Training Standards.
The Custom Multi Function Gym Fitness Equipment is a modular strength training system engineered for facilities that require flexibility without compromising structural integrity. Rather than forcing a fixed footprint onto a training floor, this system is built around a configurable platform: upright lengths, tube shapes, hole diameters, colors, and attachment combinations are all specified at the point of order. The result is a piece of equipment that matches the room, the training style, and the brand identity of the facility it occupies — whether that is a commercial gym, a private studio, or a high-end home training space.
At the core of the system is an 11-gauge 75x75mm industrial steel frame, a material specification that delivers the torsional rigidity and load stability required for heavy compound lifting. Steel unit weight can reach 948kg on full configurations, while customized frame builds may range from 500kg to 1000kg depending on layout. This mass-based stability reduces reliance on floor anchoring and keeps the structure motionless during explosive squats, heavy bench press, and dynamic pull movements.
What separates this system from a standard power rack is the depth of its configuration options. Buyers are not selecting from a fixed catalog of pre-built units; they are defining the equipment's physical and functional parameters. This approach suits facility operators who need to standardize equipment across multiple zones while adapting each station to its specific purpose.
| Parameter | Available Options | Practical Impact |
|---|---|---|
| Upright Length | 1.8m, 2.2m, 2.5m, 2.7m, 3.0m | Adapts to ceiling height and available training space |
| Tube Shape | Square, circular | Structural and aesthetic differentiation |
| Hole Diameter | Ø 20mm, Ø 25mm | Determines attachment compatibility across the range |
| Color | Black, Blue, Yellow, Red, custom | Aligns equipment with facility branding |
| Logo | Laser, CEM custom branding | Creates a unified visual identity across locations |
| Configuration | Basic rack to integrated multi-station rig | Scales from single-unit to full training zone |
The frame is fabricated from 11-gauge (75x75mm) heavy-duty industrial steel. This tubing size is a deliberate engineering choice: it provides a substantially higher moment of inertia than thinner-gauge alternatives, meaning the uprights resist bending and twisting even under asymmetric loading. In practical terms, this translates to a rack that does not develop perceptible flex during heavy squats or sudden bar drops. For a commercial facility, that rigidity is directly tied to user safety and equipment lifespan.
Steel unit weight reaches 948kg in full configuration, with customized frames ranging between 500kg and 1000kg depending on the number of stations and attachments. This mass serves a functional purpose: it lowers the system's center of gravity and resists lateral displacement during high-intensity training. While floor anchoring remains an option, the self-weight alone provides a level of anti-shake performance that lighter racks cannot match.
The entire frame undergoes professional powder coating, creating a hard, fused polymer layer that resists rust, abrasion, and chemical exposure from gym cleaning products. This finish is applied after fabrication, ensuring full coverage of welds and edges — the areas most vulnerable to corrosion in humid training environments.
The system supports a broad spectrum of strength modalities within a single footprint, reducing the need for separate single-purpose machines.
Squats, bench press, deadlifts, and overhead press are fully supported through the main upright structure, with J-hooks and safety spotter arms providing secure barbell placement and lift-off protection. Numbered height indicators and a robust pin system allow rapid, precise adjustment between users.
An optional fully bearing pulley system enables smooth cable travel for lat pulldowns, low rows, cable flyes, and functional accessory work. The bearing-based design reduces friction and wear compared to bushing-based alternatives, maintaining consistent resistance feel over time.
The upper structure accommodates a 3mm thick multi-grip pull-up bar, supporting wide, narrow, and neutral grip positions. This allows back and arm training to be integrated into the same station without additional equipment.
The rack is compatible with a wide range of attachments, including J-hooks, safety arms, band pegs, landmine attachments, dip attachments, monolifts, jammer arms, plyo boxes, lat pulldown seats, and plate/barbell storage solutions. This compatibility means the system can evolve over time as training needs change, rather than becoming obsolete when a new modality is introduced.
Uprights feature clear numbered markings, allowing trainers to record and reproduce bar heights across sessions. Combined with a robust pin system, this supports fast transitions in group training or high-traffic commercial settings.
Thickened safety arms provide critical protection during failed lifts, while sandwich hooks offer a more stable barbell resting point than standard J-hooks. These details matter in commercial environments where equipment is used by lifters of varying experience levels.
The base is equipped with anti-slip rubber foot pads or a ground protective frame, reducing the risk of floor damage and preventing unintended rig movement during dynamic training.
Integrated storage options for weight plates, barbells, and accessories keep the training area organized and reduce trip hazards — a practical consideration for facilities managing high equipment density.
| Item | Data |
|---|---|
| Type | Customizable Strength Training System / Multi-Function Squat Rack / Power Rack |
| Main Model(s) | SC-D06 / SGY06 / MF-PR-001 |
| Net Weight | 200kg (SGY06 single rack); Steel Unit Weight 948kg; Overall Frame 500kg/1000kg (Customizable) |
| Tube Specification | 11 gauge 75x75mm steel |
| Upright Lengths (Optional) | 1.8m, 2.2m, 2.5m, 2.7m, 3.0m |
| Hole Diameters (Optional) | Ø 20mm, Ø 25mm |
| Main Color(s) | Black, Blue, Yellow, Red, etc. (Customizable) |
| Surface Finish | Powder Coated |
| Logo | Customizable (Laser & CEM Custom Logo) |
| Usage Scenarios | Commercial gym, home, storage, squat rack, private studios, high-end home use |
Production is carried out in an owned manufacturing facility, with each unit passing through controlled fabrication, welding, and coating stages. The manufacturer provides ODM design and manufacturing services, supporting clients who require customized configurations, branding, or structural adaptations. Products are exported to over 80 countries and regions, supported by an efficient supply chain and one-stop service model covering design, production, and after-sales support.
Place of Origin: Shandong, China
Type: Squat Rack
Gender: Unisex
Product Name: Functional-Squat Combo Trainer
Function: Body Building
Packing: Plywood Case
Logo: Customized Logo Availabled
MOQ: 1 Set
Net Weight: 457 kg
Loading Weight: 90kg * 2
Dimension: 1940*1796*2229 mm
