Engineered for commercial gyms, garage training facilities, and functional fitness studios, this Wall Mounted Squat Rack Pull Up Rig delivers exceptional training density while minimizing floor space consumption. The wall-mounted design eliminates rear uprights, creating an open training environment with unobstructed access for squatting, benching, and pull-up variations.
Unlike freestanding power racks that consume 4-6 square meters of floor space, this wall-mounted configuration attaches directly to existing wall structures, reclaiming valuable training area. The absence of rear uprights allows for unrestricted barbell loading and easier cleaning access, while the connection to building structure provides inherent stability that exceeds freestanding alternatives.
The rig is constructed from 75x75x3mm heavy-duty steel tubing, a specification typically reserved for structural applications. The 3mm wall thickness provides exceptional load-bearing capacity and torsional rigidity, eliminating any perceptible sway even during dynamic movements such as kipping pull-ups or heavy squatting. This material selection ensures decades of daily commercial use without structural degradation.
| Station Type | Quantity | Primary Exercises |
|---|---|---|
| Squat Stations | 2 | Back squats, front squats, bench press, overhead press |
| Pull Up Stations | 3 | Pull-ups, chin-ups, leg raises, suspension training |
| Custom Configuration | Available | Mix ratio adjustable based on facility needs |
The 5-station configuration includes 2 dedicated squat stations for heavy compound movements and 3 pull-up stations for bodyweight conditioning. This balanced ratio accommodates typical commercial gym usage patterns where squat racks often experience higher peak demand. For facilities with different usage profiles, custom station configurations are available.
Four standard height configurations accommodate diverse ceiling constraints and user populations:
The entire rig system receives a professional powder coating finish, creating a durable barrier against rust, corrosion, scratches, and chemical exposure from cleaning agents. Multiple color options are available including black, red, blue, yellow, white, and custom color matching for brand integration. The powder coating process ensures consistent coverage on all surfaces, including hard-to-reach interior areas.
The rig attaches to building structure using heavy-duty anchor bolts (not included, specified based on wall construction type). Proper installation requires connection to concrete, masonry, or engineered wood studs capable of supporting dynamic loads exceeding 500kg per upright. For non-standard wall constructions, consult structural engineer for appropriate attachment methods.
The standardized 75x75mm upright design ensures compatibility with hundreds of rig attachments, including:
Beyond standard configurations, the rig supports fully custom dimensions including width between stations, overall length, pull-up bar height adjustments, and specialized attachment placements. This flexibility allows precise adaptation to unique floor plans, corner installations, or integration with existing equipment.
| Specification Category | Technical Details |
|---|---|
| Product Type | Wall Mounted Squat Rack Pull Up Rig |
| Frame Material | 75x75x3mm heavy-duty steel tube |
| Station Configuration | 5 stations (2 squat stations + 3 pull-up stations) |
| Custom Station Layout | Available upon request |
| Rig Height Options | 230cm / 250cm / 270cm / 360cm |
| Custom Dimensions | Width, depth, station spacing customizable |
| Surface Finish | Powder coating finish with multiple color options |
| Attachment Compatibility | Compatible with standard rig/rack attachments |
| Mounting Type | Wall mounted with heavy-duty anchor bolts |
| Application | Commercial gyms, garage gyms, functional fitness studios |
